Animating Responsive Grid Layout Transitions with GSAP Flip

Grid Style

The gallery uses CSS Grid. The main container defines the grid layout, spacing, padding, and overall width, while the data-size-grid attribute controls how compact or spacious the grid feels.

Each data-size-grid value adjusts the number of columns. Smaller values fit more items on screen, while larger values give each item more room. This makes it easy to see how the layout responds to the selected option.

Image proportions are handled with the aspect-ratio property, using a CSS variable defined inline in the HTML. This way, each image can keep its own shape while the grid stays clean and consistent.

.grid_gallery_container {
  display: grid;
  gap: 1.5rem;
  padding: 2rem 0;
  width: 100%;
  max-width: 1200px;
  margin: 0 auto;
}

.grid_gallery_container[data-size-grid='50%'] {
  grid-template-columns: repeat(16, 1fr);
}

.grid_gallery_container[data-size-grid='75%'] {
  grid-template-columns: repeat(10, 1fr);
}

.grid_gallery_container[data-size-grid='100%'] {
  grid-template-columns: repeat(8, 1fr);
}

.grid_gallery_container[data-size-grid='125%'] {
  grid-template-columns: repeat(6, 1fr);
}

.grid_gallery_container[data-size-grid='150%'] {
  grid-template-columns: repeat(4, 1fr);
}

.grid_gallery_item {
  will-change: auto;
  display: flex;
  flex-direction: column;
}

.grid_gallery_item p {
  font-size: 0.6745rem;
  text-align: left;
}

.image {
  width: 100%;
  aspect-ratio: var(--aspect-ratio, 1 / 1);
  background-size: cover;
  background-position: center;
  filter: brightness(0.8);
  transition: filter 0.3s cubic-bezier(0.25, 0.1, 0.25, 1);
}

.image:hover {
  filter: brightness(1);
}

@media screen and (max-width: 768px) {
  .grid_gallery_container[data-size-grid='50%'],
  .grid_gallery_container[data-size-grid='75%'],
  .grid_gallery_container[data-size-grid='100%'],
  .grid_gallery_container[data-size-grid='125%'],
  .grid_gallery_container[data-size-grid='150%'] {
    grid-template-columns: repeat(3, 1fr);
  }
}

@media screen and (min-width: 768px) and (max-width: 1024px) {
  .grid_gallery_container[data-size-grid='50%'] {
    grid-template-columns: repeat(10, 1fr);
  }

  .grid_gallery_container[data-size-grid='75%'] {
    grid-template-columns: repeat(8, 1fr);
  }

  .grid_gallery_container[data-size-grid='100%'] {
    grid-template-columns: repeat(6, 1fr);
  }

  .grid_gallery_container[data-size-grid='125%'] {
    grid-template-columns: repeat(5, 1fr);
  }

  .grid_gallery_container[data-size-grid='150%'] {
    grid-template-columns: repeat(3, 1fr);
  }
}

Alright, let’s make it interactive.

JavaScript

Create a smooth grid layout transition using the GSAP Flip plugin

Each button controls how dense the grid layout feels. When a button is clicked, the code first checks whether an animation is already running. If it is, the click is ignored to keep everything stable. Next, it reads the target grid size from the button’s data-size attribute. If that size is already active, the click is also ignored since there’s nothing to update.

When a real change is needed, interaction is temporarily locked and the current layout of all grid items is captured. The grid size is then updated by changing the data-size-grid attribute, which triggers a new CSS grid layout.

The active button state is updated to reflect the new selection, and GSAP Flip animates the grid smoothly from the previous layout to the new one. Once the animation finishes, interaction is unlocked and the grid is ready for the next input.

// Flag to prevent multiple animations at the same time
// currentGridSize stores the active grid size
let animated = false,
  currentGridSize = gridGallery.dataset.sizeGrid || "75%";

// Loop through each configuration button
triggerButtons.forEach((btn) => {
  // Add click event listener to each button
  btn.addEventListener("click", () => {
    // Prevent interaction if an animation is already running
    if (animated) return;

    // Get the target grid size from data-size attribute
    const targetSize = btn.dataset.size;

    // If the clicked size is already active, do nothing
    if (targetSize === currentGridSize) return;

    // Lock animation state
    animated = true;

    // Capture the current position and size of all grid items
    const state = Flip.getState(allGridItem);

    // Update grid size using data attribute (used by CSS)
    gridGallery.dataset.sizeGrid = targetSize;

    // Update current grid size state
    currentGridSize = targetSize;

    // Remove "active" class from all buttons
    triggerButtons.forEach((btn) => {
      btn.classList.remove("active");
    });

    // Add "active" class to the clicked button
    btn.classList.add("active");

    // Animate elements from the previous state to the new layout
    Flip.from(state, {
      duration: 0.8, // Animation duration in seconds
      ease: "expo.inOut", // Smooth easing for natural motion
      onComplete: () => {
        // Unlock animation after completion
        animated = false;
      },
    });
  });
});

Version 2

Compared to the simpler version, the core logic stays exactly the same: button clicks, state checks, layout updates, and the Flip animation all work in the same way. The main difference here is how the transition feels visually.

This version adds a visual effect to the grid container itself. While the items are rearranging, the entire grid briefly blurs and becomes brighter, then smoothly returns to its normal state. This effect runs in parallel with the Flip animation and helps soften the moment when the layout changes, making the transition feel more polished and intentional.

This version also uses a stagger with a random order, so items don’t all move at the same time. Because of the staggered motion, the total transition time is calculated by combining the Flip duration and the stagger amount. The interaction lock (animated) is still released only after the main Flip animation finishes, ensuring everything stays stable before the next interaction.

In short, this version doesn’t change how the grid works, but it enhances how it feels by adding depth, rhythm, and subtle visual feedback during the transition.

// Flag to prevent multiple animations at the same time
// currentGridSize stores the active grid size
let animated = false,
  currentGridSize = gridGallery.dataset.sizeGrid || "75%";

// Loop through each configuration button
triggerButtons.forEach((btn) => {
  // Add click event listener to each button
  btn.addEventListener("click", () => {
    // Prevent interaction if an animation is already running
    if (animated) return;

    // Get the target grid size from data-size attribute
    const targetSize = btn.dataset.size;

    // If the clicked size is already active, do nothing
    if (targetSize === currentGridSize) return;

    // Lock animation state
    animated = true;

    // Capture the current position and size of all grid items
    const state = Flip.getState(allGridItem);

    // Update grid size using data attribute (used by CSS)
    gridGallery.dataset.sizeGrid = targetSize;

    // Update current grid size state
    currentGridSize = targetSize;

    // Remove "active" class from all buttons
    triggerButtons.forEach((btn) => {
      btn.classList.remove("active");
    });

    // Add "active" class to the clicked button
    btn.classList.add("active");

    const flipDuration = 1;
    const staggerAmount = 0.3;
    const totalFlipDuration = flipDuration + staggerAmount;

    // Animate elements from the previous state to the new layout
    Flip.from(state, {
      absolute: true,
      duration: flipDuration, // Animation duration in seconds
      ease: "expo.inOut", // Smooth easing for natural motion
      onComplete: () => {
        // Unlock animation after completion
        animated = false;
      },
      stagger: {
        amount: staggerAmount,
        from: "random",
      },
    }).fromTo(
      gridGallery,
      {
        filter: "blur(0px) brightness(100%)",
        willChange: "filter",
      },
      {
        duration: totalFlipDuration,
        keyframes: [
          {
            filter: "blur(10px) brightness(200%)",
            duration: totalFlipDuration * 0.5,
            ease: "power2.in",
          },
          {
            filter: "blur(0px) brightness(100%)",
            duration: totalFlipDuration * 0.5,
            ease: "power2",
            delay: 0.5,
          },
        ],
      },
      0
    );
  });
});

Conclusion

This example highlights just one of many possible directions. By keeping the core logic the same and only adjusting animation details, the grid transition can feel subtle, dynamic, or more expressive. Small tweaks to timing, stagger, or visual effects can already open up a wide range of variations.

This flexibility makes the setup easy to adapt and extend, encouraging experimentation without adding unnecessary complexity.

And that’s it! We’ve built an interactive grid layout transition using the GSAP Flip plugin. I hope this tutorial was useful. Thanks for reading 😃
